Weld Neck Flanges
V M ALLOYS is a prominent manufacturer of stainless steel cross, carbon steel cross and alloy steel cross fittings, commonly known as a 4-way pipe fitting. Cross tee usuAlloy generates high stress on as temperature changes, because they are at the center of four connection points. In comparison, a tee is steadier than a cross, as a tee behaves like a three-legged stool, while a cross behaves like a four-legged stool.
Various grades of pipe caps manufactured by V M ALLOYS includes 304/304L, 316/316L, 321, 347, 317L, 310S, 904L, Duplex, Alloy 201, Alloy 800H, Alloy C276, Cupro Nickel, Alloy 400, Alloy 625 and Alloy 600. Our stocking program includes stainless steel pipe caps and carbon steel pipe caps of standard sizes and grades. Our specialty is to offer our customers with pipe caps in various shapes – round, square, rectangular or other special shapes.
Welding Neck Flange, WN Forged Flanges, Weld Neck Flanges Production Range
| Size | 1/2″ (15 NB) to 48″ (1200NB) |
| Standards | ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings |
| Pressure Ratings | Class 150, Class 300, Class 400, Class 600, Class 900, Class1500, Class 2500 | PN6, PN10, PN16, PN25, PN40, PN64 etc. |
| Carbon Steel Weld Neck Flanges | ASTM A105/A105N, A350 LF1, LF2 CL1/CL2, LF3 CL1/CL2, A694 F42, F46, F48, F50, F52, F56, F60, F65, F70, A516.60, 65, 70 (Spectacle Blind Flange, Spacer Ring/Spade Flange), Steel RST37.2, C22.8 |
| Stainless Steel Weld Neck Flanges | ASTM A182 F202, F304/304L/304H, F316/316L, F316H, F316TI, F310, F321, F904L |
| Alloy Steel Weld Neck Flanges | ASTM A182 F1, F5, F9, F11, F22, F91 |
| Special Alloy Weld Neck Flanges | Duplex, Super Duplex, Nickel Alloys |
| Flange Face Type | Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ) |
| Coating/Surface Treatment | Anti-rust Paint, Oil Black Paint, Yellow Transparent, Zinc Plated, Cold and Hot Dip Galvanized |
| Value Added Services | CNC Machining, Customised Flanges |
Marking & Packing
Products are packaged to ensure that there is no damage during transit. In case of exports, standard export packaging is done in wooden cases. All elbow fittings are marked with Grade, Lot No, Size, Degree and our trade mark. On special requests we can also, make custom marking on our products.
Quality Assurance
At V M ALLOYS, all fittings and flanges are subject to strict inspection at each stage of the production process, from starting material purchasing to product dispatch. They are visually examined for conformity to ASTM, ASME, MSS, DIN, EN, and JIS codes and standards. Upon request, official certified Inspection Agencies can be called in to witness the material reports, dimensions and quality conformity of products.
Test Certificates:
Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report
Technical Information – Specifications, Dimensions Threaded/Screwed Flanges
- ANSI/ASME B16.5 Welding Neck Flange 150lb
- ANSI/ASME B16.5 Welding Neck Flange 300lb
- ANSI/ASME B16.5 Welding Neck Flange 400lb
- ANSI/ASME B16.5 Welding Neck Flange 600lb
- ANSI/ASME B16.5 Welding Neck Flange 900lb
- ANSI/ASME B16.5 Welding Neck Flange 1500lb
- ANSI/ASME B16.5 Welding Neck Flange 2500lb
- ANSI/ASME B16.47 Series B Weld Neck Flange 75lb
- ANSI/ASME B16.47 Series B Weld Neck Flange 150lb
- ANSI/ASME B16.47 Series B Weld Neck Flange 300lb
- ANSI/ASME B16.47 Series B Weld Neck Flange 600lb
- ANSI/ASME B16.47 Series B Weld Neck Flange 400lb
- ANSI/ASME B16.47 Series B Weld Neck Flange 900lb
- ANSI/ASME B16.47 Series A (MSS SP44) Weld Neck Flange 150lb
- ANSI/ASME B16.47 Series A (MSS SP44) Weld Neck Flange 300lb
- ANSI/ASME B16.47 Series A (MSS SP44) Weld Neck Flange 400lb
- ANSI/ASME B16.47 Series A (MSS SP44) Weld Neck Flange 600lb
- ANSI/ASME B16.47 Series A (MSS SP44) Weld Neck Flange 900lb
